Place of Origin:
GUANGZHOU
Brand Name:
TIANYUE
Certification:
3c.ce
Model Number:
TY-RGV20
Document:
| Rail-Guided Vehicle | Technical Parameters |
|---|---|
| Name | Medium RGV |
| Model | RGV20 |
| Track Form | Straight, circular, curved |
| Track Material | Aluminum profile, GB/T11264 light rail |
| Load | 50kg-10T, customizable |
| Speed | ≤200m/min, customizable |
| Acceleration | ≤1m/s² |
| Speed Control Method | Frequency conversion/servo |
| Transfer Method | Chain, belt, telescopic fork, customizable lifting fork station |
| Positioning Method | Laser/barcode |
| Travel Positioning Accuracy | ±5mm |
| Power Supply | Sliding contact line |
| Communication Method | Optical communication, wireless communication, power line carrier, leaky wave |
| Control Method | Manual/automatic |
Additional notes: "Rail-guided automatic guided vehicle, featuring high speed, high reliability, and low cost. It is widely used in logistics systems, mainly for material transport and workshop loading."
"Note: Custom design requirements can be accepted. Data is for reference only, and the actual vehicle parameters shall prevail."
