Name: SMT Type AGV with 50kg Load Capacity Mecanum Wheel Drive and Laser Guidance for PCB Material Transport
Brand: Guangzhou Tianyue Automation Technology Co., Ltd.
SKU: TY-FB-SMT-50
Availability: InStock

Home > Products > AGV Automated Guided Vehicle >

SMT Type AGV with 50kg Load Capacity Mecanum Wheel Drive and Laser Guidance for PCB Material Transport

Omnidirectional AGV Automated Guided Vehicle

50KG Load AGV Automated Guided Vehicle

Place of Origin:

GUANGZHOU

Brand Name:

TIANYUE

Certification:

3c.ce

Model Number:

TY-FB-SMT-50

Document:

Product Brochure PDF

Request A Quote

Product Details

Motor Way:

Servo Motor

Drive Mode:

Mecanum Wheel

Docking Mod:

Conveyor

Size:

Customization

Power Supply:

Lithium Iron Phosphate

Appearance:

Customization

Load Weight:

50kg

Application:

SMT

Highlight:

Omnidirectional AGV Automated Guided Vehicle

50KG Load AGV Automated Guided Vehicle

Payment & Shipping Terms

Minimum Order Quantity

Packaging Details

wooden box

Delivery Time

50 work days

Payment Terms

T/T

Supply Ability

100

SMT Type AGV with 50kg Load Capacity Mecanum Wheel Drive and Laser Guidance for PCB Material Transport

Get Best Price

AGV Automated Guided Vehicle with Polyurethane Tyre Material and 1500 Kg Load Capacity for Precise ±10mm Parking Accuracy

Get Best Price

AGV Automated Guided Vehicle with 400 Kg Load Capacity 942Mm Rotational Diameter and Two-Wheel Differential Drive for Warehouse Automation

Get Best Price

Customized AGV Automated Guided Vehicle with Electromagnetic Brake System and Laser Guidance Navigation

Get Best Price

13570415240

mkliangjintian@gmail.com

Contact Now

Product Description

AGV Automated Guided Vehicle - Omnidirectional Double-Conveying SMT Type

This advanced AGV (Automated Guided Vehicle) features omnidirectional double-conveying capability specifically designed for SMT (Surface Mount Technology) material handling. With a load capacity of 30-50KG, it efficiently transports PCB material frames between loading and unloading stations.

SMT Type AGV with 50kg Load Capacity Mecanum Wheel Drive and Laser Guidance for PCB Material Transport 0

Technical Specifications

Parameter	Specification
Product Name	Dual-Belt Conveyor SMT Type AGV
Product Dimensions	Length X × Width X × Height X mm (custom design)
Product Color	Customer specified color plate
Load Mode	Dual-station docking for SMT machine integration
Load Capacity	50kg (ground friction coefficient ≥0.5)
Control Mode	Customizable per customer requirements
Guidance Mode	Laser guidance
Driving Directions	Forward, Backward, Left Turn, Right Turn, Divergence, Lateral Move, Horizontal Move
Communication Mode	Customizable per customer requirements
Driving Mode	Mecanum wheel drive
Drive Power Supply	DC 48V
Traveling Speed	Straight: 0-40m/min, Turn: 0-20m/min
Turning Radius	≥800mm
Allowable Floor Flatness	≤5mm
Operating Mode	24-hour continuous operation
Climbing Ability	≤3%
Charging Mode	Online charging (side charging)
Obstacle Sensor Safety Range	Detection distance ≤3m (adjustable), Sensor angle ≤270° (adjustable), Emergency braking < 20mm
Safety Protection	Front obstacle detection + dual safety edge anti-collision + emergency stop switch
Alarm Forms	Sound and light alarm
Working Noise	Normal operation < 70dB(A)
Battery	48V 60Ah lithium battery
Design Life	>10 years

SMT Type AGV with 50kg Load Capacity Mecanum Wheel Drive and Laser Guidance for PCB Material Transport 1

Key Applications

This AGV system transports PCB material frames to designated loading/unloading machines, enabling efficient recycling of empty PCB material frames and transportation of full material frames. The system provides high flexibility and is integrated with intelligent logistics scheduling and ERP systems to facilitate intelligent distribution, turnover, and warehousing operations for parts, semi-finished products, and finished goods.

System Integration Benefits

Omnidirectional movement capability for maximum flexibility
Intelligent logistics scheduling system integration
ERP system connectivity for comprehensive operational management
24/7 continuous operation capability
Advanced safety features for reliable performance

SMT Type AGV with 50kg Load Capacity Mecanum Wheel Drive and Laser Guidance for PCB Material Transport 2

SMT Type AGV with 50kg Load Capacity Mecanum Wheel Drive and Laser Guidance for PCB Material Transport 3

SMT Type AGV with 50kg Load Capacity Mecanum Wheel Drive and Laser Guidance for PCB Material Transport 4
