Place of Origin:
GUANGZHOU
Brand Name:
TIANYUE
Certification:
3c.ce
Model Number:
TY-UGV-TK-50
Document:
| Parameter | Value |
|---|---|
| Chassis Size (mm) | 1070 x 700 x 365 |
| Parking/Braking Mode | Motor parking/braking |
| Chassis Mass (kg) | 140 |
| Communication Protocol | CAN |
| Independent Left and Right Shock Absorption | Yes |
| Vertical Load (kg) | 800 |
| Hanging Christie Suspension | Yes |
| Operating Speed (km/h) | 0-4.2 |
| Chassis Material | Q235 |
| Range (km) | 20 |
| Ground Clearance (mm) | 118 |
| Wading Depth (cm) | 10 |
| Maximum Climbing Angle | 30° no load / 15° full load |
| Drive Wheel Diameter (mm) | 213 |
| Battery | 48V / 40AH |
| Obstacle Crossing Height (cm) | 20 |
| Charging Method | 48V / 20A charger manual charging |
| Protection Level | IP22 |
| External Power Supply | 24V / 15A-12V / 15A-5V / 4A |
| Working Temperature (°C) | -10 to 50 |
