Name: 48V AGV Mecanum Wheel Drive Assembly 4 Wheel Load 500KG Diameter 180mm
Brand: Guangzhou Tianyue Automation Technology Co., Ltd.
SKU: TYM-500-25-400w1
Availability: InStock

Home > products > AGV Mecanum Wheel Drive Components >

48V AGV Mecanum Wheel Drive Assembly 4 Wheel Load 500KG Diameter 180mm

48V mecanum wheel drive

mecanum wheel drive 500KG

Diameter 180mm mecanum wheel drive

Place of Origin:

GUANGZHOU

Brand Name:

TIANYUE

Certification:

3c.ce

Model Number:

TYM-500-25-400w1

Document:

Product Brochure PDF

Request A Quote

48V AGV Mecanum Wheel Drive Assembly 4 Wheel Load 500KG Diameter 180mm

Product Details

Drive Mode:

Servo Motor

Wheel Diameter:

180

Voltage:

48V

Driving Power:

400W

Series Type:

Mecanum Wheel Drive

Highlight:

48V mecanum wheel drive

mecanum wheel drive 500KG

Diameter 180mm mecanum wheel drive

Payment & Shipping Terms

Minimum Order Quantity

Packaging Details

wooden box

Delivery Time

30 work days

Payment Terms

T/T

Power 1000W AGV Mecanum Wheel Drive Assembly Load 3000KG Diameter 305mm

Get Best Price

Video

1500W AGV Mecanum Wheel Drive Assembly Integrated Four Wheel Load 6000KG

Get Best Price

Video

430mm Dia AGV Mecanum Wheel Drive Assembly Shock Absorbing Load 7000KG

Get Best Price

AGV Parts Heavy Duty Mecanum Wheels Drive Assembly Power 400W

Get Best Price

13570415240

mkliangjintian@gmail.com

Contact Now

Product Description

Parameter	Specification
Model	TYM-500-25-400W1
Wheel Diameter (mm)	180
Roller Material	Imported Polyurethane
4-wheel Rated Load (kg)	300
Rated Voltage (V)	48
Rated Power (W)	200-400
Rated Output Speed (rpm)	300
Rated Torque (N·m)	11.5
Shock Absorption Type	Spring Shock Absorption
Reduction Ratio	1:09
Encoder Type	Incremental
Maximum Speed (m/min)	180
Normal Operating Speed (m/min)	30-60
