Place of Origin:
GUANGZHOU
Brand Name:
TIANYUE
Certification:
3c.ce
Model Number:
ML-1-20
Document:
| Picture | Diameter | Type | Load/Set | Roller Material | Width | Net Weight/Piece |
|---|---|---|---|---|---|---|
| 1 | 4" / 100mm | MW100 | 250kg | CPU | 54mm | 0.7kg |
| 2 | 4.7" / 120mm | MW120 | 300kg | CPU | 62mm | 2kg |
| 3 | 6" / 152mm | MW152 | 500kg | CPU | 80mm | 2.6kg |
| 4 | 7" / 176mm | MW175 | 600kg | CPU | 90mm | 3kg |
| 5 | 8" / 203mm | MW203 | 800kg | CPU | 105mm | 4.5kg |
| 6 | 10" / 254mm | MW254 | 1500kg | CPU | 128mm | 13.5kg |
| 7 | 11" / 280mm | MW280 | 2000kg | CPU | 145mm | 15kg |
| 8 | 12" / 305mm | MW305 | 3000kg | CPU | 156mm | 17.5kg |
| Picture | Diameter | Type | Load/Set | Roller Material | Width | Net Weight/Piece |
|---|---|---|---|---|---|---|
| 9 | 13" / 330mm | MW330 | 3500kg | CPU | 170mm | 25kg |
| 10 | 14" / 375mm | MW355 | 4500kg | CPU | 190mm | 32kg |
| 11 | 15" / 375mm | MW375 | 5000kg | CPU | 200mm | 40kg |
| 12 | 16" / 406mm | MW406 | 6000kg | CPU | 210mm | 45kg |
| 13 | 18" / 457mm | MW457 | 8000kg | CPU | 230mm | 60kg |
| 14 | 18.7" / 475mm | MW475 | 9000kg | CPU | 250mm | 75kg |
| 15 | 19" / 480mm | MW480 | 10000kg | CPU | 250mm | 80kg |
| 16 | 20" / 508mm | MW508 | 10000kg | CPU | 270mm | 88kg |
| 17 | 22" / 558mm | MW558 | 15000kg | CPU | 290mm | 110kg |
| 18 | 24" / 609mm | MW609 | 20000kg | CPU | 310mm | 143kg |
